New Equipment Model

New Equipment Model


Designed to deliver superior performance and fuel efficiency, the Develon D34 diesel engine fully meets the latest Stage V emission regulations. To optimize machine performance, the engine uses high pressure fuel injectors, air to air intercooler and electronic engine controls. 4 cycle water cooled, wastegate turbocharged, Diesel Oxidation Catalyst, Selective Catalytic Reduction and Diesel Particulate Filter.



Maximum power 100hp
Operating weight 107-11100kg
Bucket capacity 0.28
Emission standard Stage V
Engine Develon D34
Engine power 100hp @ 2000rpm
Max swing speed 10.5rpm
Max swing torque  1820kgf.m
Max traction force 4200kg
Minimum turning radius 5738mm (4 wheel steering: 3697mm)
Gradeability 70%
