DoosanDL380-7

The DL380-7  wheel loader’s performance features include higher efficiency engine output: powershift transmission with optimised hydraulic pumps, multiple power modes, Z-bar lift arm, return to dig, and limited slip differentials on both front and rear axles.

An efficient cooling system features an all-aluminium reversible fan and rubber mounts to reduce vibration.

Multiple cab improvements make your work easier and more comfortable: class-leading visibility, automatic air conditioning, improved steering column, and ergonomically placed FnR joystick controls. The air suspension multi settings seat features a right-hand control stand that’s integrated into the seat assembly for increase controllability.

And maintenance is quick and easy. Easily reach test points, oil sampling ports, and engine and coolant drains. Monitor your Doosan equipment and manage maintenance to reduce operating costs with Doosan Telematics.

Specifications

Operating weight 20600kg
Bucket capacity 3.7m3
Engine type Doosan DL08 TIER V
Rated engine performance (SAE J1995 gross)  271hp
Max. torque at rpm 1,275 Nm @ 1,300 rpm
Breakout force 140 kN
Static tipping load (straight / 40°) 15782 / 13882 kg
Std. tyres 23.5 R25 (L3)
Turning radius (tyre edge / bucket edge) 6,009 / 6,703 mm
Height at bucket pivot point mm 4175 mm

SPECIFICATIONS

Tipping Weight 16
Engine Power 271 HP
Bucket Capacity 3.7m³
Operating Weight 20.6kg
