High productivity and Fuel economy – Doosan’s DNA

The fully automatic transmission — with 3 selectable transmission modes — uses a vehicle control unit, so the engine’s computer and transmission control system constantly communicate with each other to reduce fuel consumption and increase performance.

Operators can choose between 3 engine modes - by simply pushing a button to toggle between the modes ? to adjust performance to the application and work with the right balance of power and fuel economy.


Operating weight 13545 kg
Bucket capacity 2,4 m3
Engine type 6 cylinders – EU Stage IV compliant
Max. engine performance (SAE J1995 gross) 172 hp
Max. torque 804 Nm at 1400 rpm
Static tipping load (straight / at full turn) 11135 kg / 9.835 kg
Height at bucket pivot point (Standard lift / High lift) 3858 mm / 4.302 mm
Breakout force 107 kN
Standard tyres 20.5 R25
Wheelbase 3010 mm
Turning radius (tyre side / bucket edge) 5475 mm / 6045 mm
Overall length 7475 mm
Overall height 3280 mm
